Quadnet Control Panel Engineering and Commissioning Manual
Access Levels and Codes
The menu system is divided into four access levels in order to restrict access to those who require it. For
simple indication the status of the Controls Enabled light will show the level selected as follows;
Access to the menu system requires either the operation of the enable controls key for access to Access
Level 2A (User), or the correct entry of the relevant code for access to all other levels, in order to protect
against unauthorised access to the system. The codes may be changed using the Quadnet OSP software.
A valid access level code must be entered in order access any of the menus.
Menu examples shown below are for the V3 control panel. Menus in some earlier panel versions may differ.
Access Level 1 (Normal):
Controls Enabled LED off
At Access Level 1 (Normal), the main Fire Alarm Controls are disabled and the Controls Enabled LED is
switched off.
A valid access level code must be entered in order access any of the menus.
Delay Override
To comply with EN54-2 Clause 7.11.1d, a non-delayed manual call point (MCP) should be located
next to the CIE to override the delayed output by a manual operation.
Access Level 2A (User): Controls Enabled LED on
At Access Level 2A (User), the main Fire Alarm Controls are enabled, and the following System Controls
are accessible:
Delay Override
The Delay Override function overrides any programmed delays.
Test Display
The Test Display function causes the panel LEDs to illuminate, and the LCD screen to blacken, and
the panel buzzer to sound in order to verify their correct operation.
Press the Esc key to exit to the previous menu.
