Quadnet Control Panel Engineering and Commissioning Manual
60
Technical Data
Control Panel
Quadnet Control and Indicating Equipment
Dimensions
W x H x D
445mm x 445mm x 110mm
No. of zones
128 zones
Number of loops
Up to 4 loops via plug-
in loop cards
(1 included as standard with panel)
No of devices
Maximum of 200
devices or maximum of
450 DLUs per loop
(whichever is reached first)
Device labels
31 characters
LCD display
Graphic display
Field 1 (top)
Field 2
Field 3
Field 4 (bottom)
Control Panel Information Window
Active Information Window
Prompt Window
Network Information Window
LED Indication
Fire
Fault
Disabled
Test
Power
Red - steady in fire
Yellow - intermittent (0.3s 0n, 2.1s off)
- pulsed (0.3s 0n, 0.5s off)
Yellow - continuous
Yellow - pulsed (0.3s on, 0.5s off)
Green - continuous for power on
Audible Indication
2.5kHz Buzzer
Continuous in fire
Intermittent (0.3s on, 2.1s off) in fault
Keypad
4 way dedicated
17 way alphanumeric
Fire Alarm Controls
System Controls
Event log
1000 events
Inputs and Outputs
Relay Outputs x 4
Monitored Outputs x 2
Monitored Inputs x 4
Volt free contacts SPCO
30V DC @ 1A max per contact
2 x 24V conventional monitored outputs
Fire, Fault, Signal, Technical Alarm
10k EOL, 200mA max per circuit
4 x resistance monitored inputs
3k3 EOL, 680R firing resistor
Auxiliary Power Output
Working Range
20 – 31V DC
Power Supply
Working Range
22.5 – 32V DC
Nominal Loop Operating Voltage
40V DC
Max loop current
500 mA
Response Times
First fire alarm event
New zone in alarm
Activate 32 alarm
zones
+ve O/C detection
-ve O/C detection
spur O/C detection
Missing device
detection
1s
<10s
3s
1s
<10s
<35s
<35s
Environmental Data
IP Rating 30
Ambient Temp Range +5
o
C to +40
o
C
Note: Refer to the relevant sections in the manual for full details of input and output ratings
