Resistor Colour Codes
On colour coded resistors the band at one end will be spaced further apart than the others. The resistor
should be viewed with this band to the right as follows, reading from the left and side of the resistor:
Band
4 Band
Codes
5 Band
Codes
1
1
st
Digit
1
st
Digit
2
2
nd
Digit
2
nd
Digit
3
Multiplier
3
rd
Digit
4
Tolerance
Multiplier
5
-
Tolerance
Colour
Digit
Multiplier
Black
0
1
Brown
1
10
Red
2
100
Orange
3
1,000
Yellow
4
10,000
Green
5
100,000
Blue
6
1,000,000
Violet
7
-
Grey
8
-
White
9
-
Gold
-
0.1
Silver
-
0.001
