Quadnet Control Panel Engineering and Commissioning Manual
6. Day / Night Mode 1. Override into Day Mode
This function allows the user to override any pre-programmed Day / Night timing information and
force the system into the less sensitive Day Mode. This will cause the panel buzzer to sound and a
disablement to be written to log.
6. Day / Night Mode 2. Override into Night Mode
This function allows the user to override any pre-programmed Day / Night timing information and
force the system into the more sensitive Night Mode. This will cause the panel buzzer to sound and
a disablement to be written to log.
6. Day Night Mode 3. End all Overrides
This function ends any override on the Day / Night Mode, and all programmed actions are
reinstated. The control panel event log will indicate that all actions have been reinstated
6. Day Night Mode 4. View Day / Night Setting
This function allows the user to view the start and finish times for each day.
7. Engineer Controls 1. Loop Controls 1. Stop Loop
This function performs a complete shutdown of every device on the chosen loop. To ensure that
every device is properly shutdown, it is important to stop the loop before removing power from the
loop. If this is not done, it may cause random faults and stoppages during subsequent initialisation.
The loop must also be stopped before removing/adding/replacing devices. Should problems occur
during initialisation, stop the loop and wait for approximately five minutes before initialising the loop
again. The previously improperly shutdown device should reboot successfully.
7. Engineer Controls 1. Loop Controls 2. Fast Init
This function may be termed Fast Initialisation, and is only suitable for restarting the loop if the loop
configuration has not been altered in any way. Always wait at least 3 minutes between stopping a
loop and reinitialising.
7. Engineer Controls 1. Loop Controls 3. Std Init: Autolearn Loop
This function instructs the control panel to perform its addressable circuit initialisation, or to
autolearn the loop devices. Previous loop map data is overwritten, so only perform this function on
new systems where a complete configuration reprogram will be completed. It starts this process
from Circuit End 1 and collects data on device type, position & serial number, and allocates a
Device Address. Please note that even though this panel does not support spurs, the control panel
will still check for their presence. Always wait at least 3 minutes between stopping a loop and
reinitialising.
