Quadnet Control Panel Engineering and Commissioning Manual
7. Engineer Controls 2. View / Edit Attributes 6. View no. of Devices Programmed
This function allows the user to view the loop devices programmed and compare with the loop
devices present.
7. Engineer Controls 2. View / Edit Attributes 7. View no. of Devices in Last Init
This function allows the user to check the number of devices initialised on the system.
7. Engineer Controls 3. Direct Commands 4. Find Device
This function allows the user to switch on the LED and sounder (if they are present) at any device
on the loop in order to aid in locating its position. It cannot be used to turn on the LED of I/O
Modules, since this would also turn on the output which would not usually be desirable.
Up, Down and Esc options allow the adjacent devices to be located, and the test to be ended.
7. Engineer Controls 4. Loops
This function allows the user to switch on or off any used or unused loops. Please ensure that any
loop cards in use are fitted and switched on.
7. Engineer Controls 5. Printer
This function allows the engineer to change printer settings for the optional onboard printer and to
print various reports on demand.
The engineer can turn printing on or off. If printing is turned on, the engineer can select which local
events get printed ‘live’ (all events, or any combination of one or more of the following: fires, faults,
panel events).
The engineer can also manually print out
• the event log (either all events or a selection by range)
• device configuration (one device on a selected loop or all devices on a selected loop)
• a printer test
• a list of current warnings
• a list of current tests
• a list of current faults
• a list of current disables
7. Engineer Controls 6. Clear All OSP Labels
WARNING: This function will erase all device labels from the system.
