5-48
Vacuum Sets
Parameter Default Min ÷ Max Description
Vacuum Sets:
I Max: ## [Amp]
40 10 ÷ 50 Maximum current from the main card to the vacuum motor.
Vacuum Sets:
I Nom: ## [Amp]
18 5 ÷ 20 Rated current; with T Nom manages the amperometric protection
(alarm + stop vacuum motor).
Vacuum Sets:
T Nom: ## [s]
30 1 ÷ 100 Rated timer; with I Nom manage the amperometric protection (alarm
+ stop vacuum motor).
Vacuum Sets:
T Off: ## [s]
20 0 ÷ 30 Delay of switching on of the vacuum motor when the switch is
pressed.
Vacuum Sets:
T reset: ## [s]
60 0 ÷ 100 Timing of reset amperometric protection (overcurrent).
Vacuum Sets:
Eco Speed: ## [V]
17 15 ÷ 20 Value of Voltage reduction of vacuum motor, during ECO mode
Vacuum Sets:
Rit Up: ## [s]
3 0 ÷ 10 Parameter not managed.
Vacuum Sets:
optional3: ##
0 0 Parameter not managed.
Vacuum Sets:
optional2: ##
0 0 Parameter not managed.
Vacuum Sets:
optional1: ##
0 0 Parameter not managed.
