Fimap MXR - Traction Sets

5-49
Traction Sets
Parameter Default Min ÷ Max Description
Traction Sets:
Acc Ramp: #.# [s]
1.5 0.5 ÷ 5.0 Acceleration ramp. The time necessary to arrive at the maximum
speed.
Traction Sets:
Dec Ramp: #.# [s]
0.7 0.5 ÷ 5.0 Deceleration ramp. The time necessary to stop the machine when the
safety lever is released.
Traction Sets:
Rev Ramp: #.# [s]
0.7 0.5 ÷ 5.0 The time necessary to invert the way.
Traction Sets:
FW Speed: ### [%]
100 20 ÷ 100 Maximum speed in forward way (expressed in %).
Traction Sets:
BW Speed: ### [%]
60 20 ÷ 100 Maximum speed in reverse way (expressed in % respect the maximum
speed in forward way).
Traction Sets:
Min Speed: ### [%]
0 0 ÷ 20 Minimum speed when the safety lever is pressed.
Traction Sets:
Ref 0: #.# [V]
7 0 ÷ 150 Minimum voltage of the potentiometer when released.
Traction Sets:
Ref FW: #.# [V]
9 5 ÷ 150 Maximum voltage of the potentiometer in forward speed when safety
lever is pressed.
Traction Sets:
Ref BW: ## [V]
9 5 ÷ 150 Maximum voltage of the potentiometer in backward speed when safety
lever is pressed.
Traction Sets:
Ref DB: 0.### [V]
0.200 0.000 ÷ 0.500 Potentiometer dead band
Traction Sets:
Brake Del: ### [S]
1.5 0.0 ÷ 10 Engaging time of electronic brake when the machine is stopped.
Traction Sets:
Mode1 V: ## [%]
50 10 ÷ 100 Voltage setting for the curve speed reduction microswitch.
Traction Sets:
Mode1 I: ## [A]
25 0 ÷ 90 Current intensity setting for the curve speed reduction microswitch.
Traction Sets:
Runaway: ### [Volt]
12 0 ÷ 20 Parameter not managed.
Traction Sets:
optional3: ##
0 0 Parameter not managed.
Traction Sets:
optional2: ##
0 0 Parameter not managed.
Traction Sets:
optional1: ##
0 0 Parameter not managed.
Traction Sets:
I Max: ## [Amp]
70 10 ÷ 70 Maximum output from the main card to the traction motor.
Traction Sets:
I Nom: ## [Amp]
20 5 ÷ 30 Rated Current; with T Nom detect the amperometric protection
threshold. (Alarm + stop traction motor).
Traction Sets:
T Nom: ## [s]
10 1 ÷ 10 Rated Timer; with I Nom detect the amperometric protection thresh-
old. (Alarm + stop traction motor).
