Fimap MXR - Recommended Spare Parts

7-63
7.5 Technical Features
TECHNICAL DESCRIPTION U/M Mxr
Squeegee width mm 705
Optional Squeegee width mm 800
Vacuum Motor Stages Nr 2
Squeegee adapter type Vertical
Vacuum Motor Power W 310
Vacuum Motor Voltage V 24
Vacuum Motor Depression mmH
2
O 970
Recovery Tank l 75
7.6 Consumable Spare Parts
PN Description
Squeegee 705mm
219451 RUBBER KIT 33 SHORE
219452 RUBBER KIT 40 SHORE PU
219453 LATEX RUBBER KIT
427251 WHEEL D=80 L=23 SUPERLAN GRAY
Squeegee 800mm
221391 RUBBER KIT 33 SHORE SP=4
221392 RUBBER KIT 40 SHORE PU SP=4
221393 RUBBER KIT LATEX SP=4
427251 WHEEL D=80 L=23 SUPERLAN GRAY
Carbon Brushes
424210 VACUUM MOTOR CARBON BRUSHES
7.7 Recommended Spare Parts
PN Description
222453 VACUUM MOTOR 24V 310W H950 2ST
436198 VACUUM HOSE D38x980
436196 DRAIN HOSE D.38x1474 D.50 W/CAP
430957 STRAIGHT ADAPTER D=40 TERGI 2010
436120 BUMPER WHEEL D=100 H=20
436190 GAS SPRING 16-1 L=146 L=40 F=150 N
436195 FLOATER PROTECTION D=62 d=47 S=3
436361 FILTER D.103x25 AU PPI 10
