Finn MBH6 - Floor Assembly

MBH6 MR1108 Rev. A
99
WHEN ORDERING PARTS, BE SURE TO STATE
SERIAL NUMBER OF MACHINE
FLOOR ASSEMBLY
Ref. No. Part Number Description No. Req’d
1 075215-02 Floor Idler Shaft 1
2 075220 Floor Take-Up Bearing 2
3 075218 Live Floor Sprocket - (8-Tooth) 1-1/2 in. Bore 4
4 075219 Take-Up Bearing Frame 2
5 075606 Bearing 1
6 075285 Front Chain Guard Weldment 1
7 A2755-001 Floor Drive Shaft 1
8 053023 2 Piece Coupling, 2 in. x 2 in. I.D., Steel 1
9 052989 Floor Gearbox 1
10 075230-01 Hydraulic Motor 1
11 A3092-001 Mount Planetary Assembly,Part B 1
12 A3221-001 Mount Planetary Assembly, Part A 1
13 A2946-001 Clean-out Cover 1
14 A3070-001 Planetary Cover 1
15 A3438-001 Floor Pan 1
16 A0161-001 Wheel Stud 9
NOT SHOWN
075583 Floor Chain 1
