Finn MBH6 - Airlock Assembly

MBH6 MR1108 Rev. A
93
WHEN ORDERING PARTS, BE SURE TO STATE
SERIAL NUMBER OF MACHINE
AIRLOCK ASSEMBLY
Ref. Kit No.
No. Ref. Part Number Description Req’d
1  075230-01 Hydraulic Motor 1
2  075204 Airlock Gearbox 1
3  075207 Sprocket 1
4  045201 Chain-Chain Couplings 1
5  075216 Bushing 1
6  045199 Coupling, Chain, Taper-Lock 1
7  075210 Airlock Guard Assembly 1
8  F605-0021 Cover Guard 2
9  F705-0034 Airlock Filler Cover 1
10  F605-0131 Airlock Filler Support 1
11  075239 Airlock Flange Bearing 2
12  075926 Knife, 16 x 25 Airlock 2
13  075927 Knife Clamp, 16 x 25 Airlock 8
14  052737 4 in. Bolted Pull Ring 1
15  A2745-001 Discharge Bottom Pan Weldment 1
16  075611 Discharge Gasket 1
17  075740 Transition Weldment 1
18  075224 Overcenter Draw Latch 4
19  055374 4 in. Male Nyglass Adapter 1
NOT SHOWN
 075762-02 Airlock Right Hand Bracket 2
 075762-01 Airlock Left Hand Bracket 2
055517 Gearbox Gasket 1
012520 Brass Bulkhead Fitting 1
007705 Grease Fitting 1
 Lincoln Lube 90º Swivel Fitting 2
 Lincoln Lube Grey Grease Line 7 in. Long 1
 1/2 in. NPT Pipe Plug 1
 1/4 in. NPT Plug 1
KITS AND MARKERS
 A2567-001 Air Lock Assembly
 Standard Hardware Item
