Finn MBH6 - Radiator Assembly

MBH6 MR1108 Rev. A
91
WHEN ORDERING PARTS, BE SURE TO STATE
SERIAL NUMBER OF MACHINE
RADIATOR ASSEMBLY
Ref. No. Part Number Description No. Req’d
1 005861 Zinc Plated Steel Snubbing Washer 6
2 031542 1 Qt. Overflow Bottle Assembly 1
3 A0959-002 Clamp, T-Bolt Band, 1.5 in. Nom. Dia. 2
4 031521 Pump Assembly, Fuel Feed 1
5 031522-00 Fuel Water Separator 1
6 A2160-001 Engine ECU 1
7 A2796-001 Radiator Fan 1
8 A2871-001 Fan Standoff Hub 1
9 A2639-024 Adapter Fitting, M33 ORS x 1 in. I.D. Hose 1
10 A2895-001 Oil Hose, SAE100R1, 1 in. I.D. 1
11 A3295-001 Oil Fill Port - Extension Assembly 1
12 A3582-001 Blower Mount 1
13 075290 Blower with Flywheel Adapter 1
14 A4877-001 Filter Mount Cover 1
15 A4878-001 Filter Mount Weldment 1
16 A3968-001 Isolator Stud, 1/4 - 20 4
17 A3997-001 Remote Oil Drain Hose Assembly 1
18 A4013-001 Vibration Isolator 6
19 A3103-001 Belt Guard 1
20 A3100-001 Radiator Core 1
21 A3110-001 Isolator Mount Bracket 1
22 A3109-001 Radiator Bracket 1
23 031538 Radiator Mount Isolator, Upper 1
24 031539 Radiator Mount Isolator, Lower 2
25 031537 Plain Washer, 0.500 x 2.00 x 0.125 2
NOT SHOWN
A3397-001 Vinyl-Coated Steel Spring Clip 1
