Finn MBH6 - Dust Suppression System

MBH6 MR1108 Rev. A
105
WHEN ORDERING PARTS, BE SURE TO STATE
SERIAL NUMBER OF MACHINE
DUST SUPPRESSION SYSTEM
Ref. No. Part Number Description No. Req’d
1 A3091-001 Dust Suppression Manifold Adapter 1
2 A4396-001 Garden Hose Fitting, Female 1
3 371801 Dema Water Valve with Actuator 1
4 052941 1/4 in. Brass Needle Valve 1
5 A3583-001 Dust Suppression Mount Weldment 1
6 006772 Hose Barb 2
7 052734 Female Disconnect 1
8 371044-03 1/2 in. NPT Coupling 1
9 A2182-004 Hose Clamp, Worm Gear, SAE J1508 Type F, Size 16 2
10 A5055-001 Elbow, 45 degree, SS, F - F, 1/4 NPT - 1/4 NPT 1
NOT SHOWN
052481 Nozzle 1
190030 Water Hose 1
