MBH6 MR1108 Rev. A
109
WHEN ORDERING PARTS, BE SURE TO STATE
SERIAL NUMBER OF MACHINE
HYDRAULIC MANIFOLD
Ref. Kit No.
No. Ref. Part Number Description Req’d
1 075902-05 DC Valve, 4-Way, 3-Position, 21.1 GPM, D03 with Coils 1
2 075902-07 DC Valve, 4-Way, 2-Position, 21.1 GPM, D03 with Coils 1
3 075902-06 DC Valve, 4-Way, 3-Position, 21.1 GPM, D03 with Coils 1
4 FW65225 Lenz #A3105-16-12 1
5 012087 Lenz #A3105-12-12 1
6 055601 Adapter Fitting, #6 MJIC x #6 SAE Orb 6
7 075902-02 Flow Divider/Combiner Cartridge, 50/50, 12 GPM 1
8 075902-08 FC Valve Cartridge, Pc, Priority Type, 8 GPM, SAE 10 1
9 075902-04 Relief Valve Cartridge, 15 GPM, SAE 8, 50 - 3000 psi 2
10 075902-09 Relief Valve Cartridge, 26 GPM, SAE 10, 50 - 3000 psi 3
11 075902-10 FC Valve Cartridge, PC, Priority Type, 2 GPM, SAE 10 1
12 052336 Pressure Switch, 2400 psi, 1/4 NPT, NO 1
13 A4326-001 Pressure Switch, 1500 psi, 1/4 NPT, NO 1
14 055863 Solenoid, Type L, Deutsch DT04-2P 1
15 075902-03 PFC Valve Cartridge, No, 8 GPM, SAE 10 without Coil 1
16 A4327-001 DC Valve Cartridge, 3-Way, 2-Position, 5 GPM, SAE 08, No Coil 1
17 A4329-001 Hydraulic Manifold 1
18 075924 #4 SAE Socket HD Plug 3
19 055308 Lenz #A3105-4-4 1
20 A1374-001 Pressure Gauge (0 - 5000 psi) 3
21 055861 Solenoid, Type "S", Deutsch DT04-2P 1
KITS AND MARKERS
A3074-001 Hydraulic Manifold Assembly
