MBH6 MR1108 Rev. A
107
WHEN ORDERING PARTS, BE SURE TO STATE
SERIAL NUMBER OF MACHINE
TARP ASSEMBLY
Ref. Kit No.
No. Ref. Part Number Description Req’d
1 A2739-001 Tarp Mounting Bracket - Driver Side 1
2 A2738-001 Tarp Mounting Bracket - Passenger Side 1
3 A2692-001 Pivot Pin, 3-Spring 2
4 A2701-001 Snap Ring, 1 1/4 in. External 2
5 A2693-001 Pivot Tube 1
6 A2694-001 Spring, Spiral Torsion Spring 1-1/4 6
7 A2695-001 Clevis Pin, 1/2 in. X 2-3/4 in. 2
8 A2707-001 Bow Tube 1
9 A2693-001 Pivot Tube 1
10 A2715-001 Tarp Bow Bumper 2
11 A2716-001 Gear Motor, Tarp 1
12 A2748-001 Stub Shaft, 3/4 in. X 5-1/2 in. Axle 1
13 A2751-001 Bearing, 3/4 in. Flanged Axle Bearing with Bolts / Nuts 1
14 A2702-001 Aluminum Corner - 90 Degree 2
15 A2705-001 Tether Cable With Install Label For 90º Corner 2
16 A2743-001 Wind Deflector 1
17 A2749-001 Axle, Pre-Threaded Tarp Axle 1
18 A2714-001 Tube Arm 2
NOT SHOWN
A2570-001 Tarp, Knit Mesh, 54 in. x 128 in.
KITS AND MARKERS
A2569-001 Full Tarp Assembly
