Installation Output Circuits
2.6.5 FACP Data Bus
MS-9600(UD)LS
The FACP communicates with the ECC-50/100 over the ACS or ANN-BUS annunciator link. Wir-
ing must be connected between Terminal TB6 on the FACP and Terminal TB13 on the ECC-50/100
panel.
MS-9200UDLS
The MS-9200UDLS FACP communicates with the ECC-50/100 over the ACS or ANN-BUS
annunciator link. Wiring must be connected between Terminal TB9 on the FACP and Terminal
TB13 on the ECC-50/100 panel.
Figure 2.19 Connection for MS-9600(UD)LS to ECC-50/100
MS-9600(UD)LS
ECC-50/100
to other ACS/ANN
devices
A B
ANN
ACS
9
6
0
0
e
c
c
.
w
m
f
+ -
B+ A+ B- A- A B
ACS
SHIELD
SLC
SLC
SLC
SLC
OUT+ IN+ OUT- IN -
TB8
TB9
TB10
Figure 2.20 Connection for MS-9200UDLS to ECC-50/100
MS-9200UDLS
ECC-50/100
to other ACS/ANN
devices
A B
ANN
ACS
9
2
0
0
u
d
e
c
c
.
w
m
f
