FireClass DUO-CEL - Mechanical & Electrical Specification; Power Supply and Battery Specifications

EQUIPMENT: FIRECLASS DUO-CEL
PUBLICATION: OM_DUO-CEL_APP
ISSUE No. & DATE: 2 20/06/18
PAGE 34 of 46
12. Mechanical & Electrical Specification
Mechanical Specification
Panel
Repeater c/w PSU
Size (mm) HxWxD
273 x 365 x 110
273 x 365 x 110
Weight excluding batteries (kg)
2.2
2.2
Bentel Power Supply Specification
Panel
Repeater c/w PSU
Mains Input
230Vac
230Vac
Maximum Input Power
138W
138W
Protection
[NOT USER SERVICEABLE]
3A 250V
20mm Glass Fuse
3A 250V
20mm Glass Fuse
Input Voltage
230Vac +10% -15%
230Vac +10% -15%
Mains Frequency [Hz]
47.5 – 63
47.5 – 63
Output Voltage (Nominal)
27.15Vdc ±1%
27.15Vdc ±1%
Output Voltage Adjustment
Factory Set
Output Protection
Electronic current limiting
Cable requirements
Minimum of 1mm
2
CSA copper
protected by a 5A fuse.
Panel Integrated Power Supply Output Specification
Maximum Short Term Output Current (I max b)
1.4A
No Output
Maximum Continuous Output Current (I max a )
335mA
No Output
Minimum Output Current (I min)
29mA
No Output
DC Voltage output, Mains On
27.15V Nominal
(26.4V-28.4V)
No Output
Maximum Output current, Mains Failed
1.4A
No Output
DC Voltage Output, Mains Failed
27V-20V
No Output
Output Protection
Electronic current
limiting
No Output
Maximum ripple including switching spikes
(full load, battery disconnected)
540mV
No Output
Output Voltage Adjustment
Factory Set
(Via Bentel Power
Supply)
No Output
Battery Specification
Panel
Repeater c/w PSU
Battery charger output:
Temperature compensated float charger
28.15V 0.1V@ -10C, 26.6V 0.1V@ +55 C.
1.5A
1.5A
Battery type:
POWERSONIC
[Warning: Replace only with identical battery]
2 off
PS-1230
[12V 3.4Ah]
2 off
PS-1230
[12V 3.4Ah]
Battery capacity
Based on 24 hours stand-by.
Battery circuit protection:
[Warning: Replace only with identical type & rating of fuse]
F2AL250V
20mm fast blow
glass fuse
F2AL250V
20mm fast blow
glass fuse
Mains failed battery current (not including zone & alarm devices)
Panel
Standby (mA)
Alarm (mA)
1 Zone standard
21
60
2 Zone standard
23
63
4 Zone standard
28
76
8 Zone standard
36
84
1 Zone Twin-Wire
25
64
2 Zone Twin-Wire
31
72
4 Zone Twin-Wire
44
100
8 Zone Twin-Wire
70
130
DC powered Repeater
8
13
Mains Powered Repeater
17
22
