FireClass DUO-CEL - Panel Configuration Design Chart

EQUIPMENT: FIRECLASS DUO-CEL
PUBLICATION: OM_DUO-CEL_APP
ISSUE No. & DATE: 2 20/06/18
PAGE 44 of 46
15.8 Panel Configuration Design Chart
Table 3 – DUO-CEL Panel DIL Switch Configuration Design/Record
Switc
h
Function
Position
Actual
Setting
1
Zone 1 Latching Fire Alarm Indication
Off
Zone 1 Non-latching Fire Alarm Indication
On
2
Active fault monitoring on zones (10uF capacitor EOL)
Off
Passive fault monitoring on zones (3K9 to 6K8 resistor EOL)
(See also DIL switch 3 operation)
On
3
Normal Sounder operation
Off
Alert Sounder operation
On
4
Dependency (coincidence) Configuration mode disabled.
Off
Table 4
Zones can be configured dependency (coincidence) mode
On
5
General Alarms sounder operation
Off
Zonal Alarms sounder operation
On
6
Short Circuit Fault monitoring on zones
Off
No Short Circuit Fault Monitoring on zones (S/C = Fire Alarm)
On
7
Auxiliary 24Vdc output is always switched on
Off
Auxiliary 24Vdc output turns off briefly during panel reset.
On
8
Internal Buzzer operates for Fires & Faults
Off
Internal buzzer does not operate for Fires & Faults
On
9
Repeater Configuration mode disabled.
Off
No.____
Repeater Configuration mode active.
On
10
Sounder Expansion Board Not Fitted (8-zone panel only)
Off
NOT
USED
Sounder Expansion Board Fitted (8-zone panel only)
On
11
NOT USED
N/A
N/A
12
NOT USED
N/A
N/A
Table 4 – Zone Dependency Configuration Design/Record
Zone Number
Dependency
(YES/NO)
1
2
3
4
5
6
7
8
