1. Introduction
This document contains technical information
necessary for application design using the
FIRECLASS DUO-CEL Conventional Fire Detection
control panel.
The following supporting documentation is also
available:
 FIRECLASS DUO-CEL Sales Literature
 FIRECLASS DUO-CEL User Manual
 FIRECLASS DUO-CEL Installation and
Commissioning Manual.
 FIRECLASS DUO-CEL Log Book.
Note: References are made throughout this
document to “Fire Signal Output” and “Fire Relay
Output”. These refer to particular outputs from the
panel and are provided for specific purposes:
 Fire Relay Output: An output used to activate
ancillary fire protection equipment or systems.
For example, fire doors or plant shutdown.
 Fire Signal Output: An output used to send a
common fire warning signal to a remote fire
monitoring station.
Detailed descriptions of both outputs are provided
within the following text.
The panel is currently available as a standard
conventional panel, with a twin-wire version soon to
be released. This document describes features
available for both types of panel.
2. General Description
The FIRECLASS DUO-CEL Panel range is fully
compliant with the mandatory requirements and
selected optional requirements of EN54 parts 2 and
4.
The FIRECLASS DUO-CEL equipment range
consists of the following:
 Standard Panels:
1, 2, 4 and 8 zone versions.
 Twin-Wire Panels:
1, 2, 4 and 8 zone versions.
 Repeater:
8 zone 24Vdc & 230Vac versions.
Each panel in the range is housed in an
Acrylonitrile Butadiene Styrene (ABS) Plastic
enclosure with a combined display & control board
mounted to the back box. An ABS cover is fixed
over the display/control board, leaving the field
terminals, configuration switches, links and user
controls easily accessible.
The front cover of the enclosure clips onto the back
box and is fixed by one screw on the top and two
screws on the bottom.
The PCB cover is fitted with a polyester overlay
providing user controls and indications. All display
text is printed on the overlay, with an insert for the
zone location text that slides into a pocket in the
overlay.
User controls are locked & unlocked via a plastic
key which is inserted through a keyhole in the cover
and cannot be removed when in the ON position.
All indications are implemented using LEDs, three
of which are not visible when the enclosure front is
fitted.
The power supply and standby batteries are
housed within the panel enclosure. The power
supply is fitted underneath the PCB with the mains
supply cable terminals accessible for easy
installation. The batteries are fitted in the back box
and retained by a plastic bar which is fixed to the
back box by a single screw.
Field cable Earth shields can be terminated to a
functional earth bar located in the rear of the panel
enclosure.
2.1 Cabinet Specifications
Enclosure construction:
 Three-part high quality moulded ABS plastic
enclosure.
 Keyhole for access control key.
 14 knockouts for 20mm cable glands.
 5 mounting holes in the rear of the back box.
 Integral bezel design for surface mounting or
semi-flush mounting.
 Logo recess on the top-right of the front cover.
 Ingress Protection rating – IP30
Finish:
 Fine-texture (spark finish)
 Colour – Light Grey RAL7035
