FISCHBEIN
®
F SERIES PORTABLE SEWING MACHINES
OPERATOR’S MANUAL
REV. H 9/2011
70
MODEL MODEL F- FH HANDLE AND ELECTRIC DRIVE
Plate "H"
ITEM
QUAN.
PART NO.
DESCRIPTION
1 1 11450 Assy., Oil Pump
2 1 11453 Cap, Oil Reserve
3 1 SB83212 Screw, Soc. Btn. 8-32 X 1/2"
4 1 11472 Clamp, Garter Spring
5 4” (102mm) 85128 Tubing, Tugon 1/4" OD
6 1 SB832114 Screw, Soc. Btn. 8-32 X 1 1/4"
7 1 11475 Manifold, Outside
8 1 11478 "O" Ring
9 1 11479 "O" Ring
10 1 11364 Weldment, Manifold - Inside
11 1 F64038 Screw, Flat HD #6-40 x 3/8
12 1 11359 Clip, Tubing-Manifold (Mod-EH)
13 0.5ft (15,24cm) 85128 Tubing, Tygon 1/4" OD
14 1 11490 Fitting, Barbed
15 1 11239 Assy, Guard-Belt (Mod-EH)
16 2 SB83214 Screw, Soc. Btn. 8-32 X 1/4 BO (SP)
17 2 SB142038 Screw, Soc. Bttn 1/4-20 x 3/8 BO
18 1 11909 Drive Belt, Timing
19 1 11904 Pulley, Machine
20 1 11240 Bracket, Handle
21 1 SB142038 Screw, Soc. Bttn 1/4-20 x 3/8 BO
22 1 12500 Switch
24 1 11011 Cover, Handle
25 2 SB103238 Screw, Soc. Set 10-32 X 3/8
26 1 SC44034 Screw, Soc. Cap 4-40 X 3/4"
28 1 11808 Cord Set (Baldor Motor only) 115V
1 11777 Cord Set - 12 Voly (10 Ft.)
1 40058 Cord Set Euromotor
1 40057 Cordgrip, PG-9, Liquid Tight Pigta
29 1 11241 Handle, MOD FH
30 2 SC142034 Screw, Soc. Cap 1/4-20 X 3/4"
31 2 WS14 Washer, Spring 1/4"
32 1 11073 Strain Relief
33 1 SB103238 Screw, Soc. BTTN #10-32 x 3/8 BO
34 1 11348 Clip, Tube-Nylon
35 6 SF103238 Screw, Soc. Flat 10-32 X 3/8"
38 1 11815 Thread Stand (8 oz. or 16 oz. Cone)
39 1 11805 Nut, Wing-Washer Base-1/4-20
40 1 11804 Holder, Thread Guide and Cone
41 1 11902 Assy,Pulley-Motor Timing
42 1 67275
Motor, 115 VAC w/ Mount
(Hinge and Screws Included)
67276 Motor, 220 VAC with Mount
44 REF 11908 Screw, Sems-Pan HD 6-32 x 7/16
45 1 PT8OZWHITE Thread, Poly 8 Oz. Cone
1 36069 Owners Manual and Warranty Card
1 1-147 MODEL F Tool Kit
46 1 11801 Guard, Pulley Drive
47 2 WN8 Washer, Nylon #8
48 2 SB103214 Screw, Soc Bttn #10-32 X 1/4 BO
