fpControl MM-3 connections
2.1.5.1 Environmental specifications, physical data of the fpControl MM-3
2.2 Installation
2.2.1 Installation of the Electronic Control Unit (ECU) fpControl - GC-S
The ECU fpControl - GC-S is pre-installed. The ECU can be exchanged easily. All connections are mechanically
coded and prevent the risk of confusion.
2.2.2 Installation of the Connection Box fpControl - CB-G
The connection box is pre-installed. External components are connected in accordance with the installation manual
and the circuit diagram of the fpControl generator.
2.2.3 Installation of the fpControl - CP-G
The fpContol - CP-G is a CAN Bus module. All Fischer Panda CAN bus modules have two RJ45 ports. One for
connection to the module on the CAN bus, the second to relay the CAN bus. The last module on the CAN bus must
have a terminating resistor in the RJ45 port.
Connection by means of the Fischer Panda bus cable is mandatory.
2 x RJ45 Power supply and fpCAN
1 x 4-pole Phoenix contact socket Alternative for the external FP Bus (USER CAN BUS)
1 x 3-pole Phoenix contact socket external transformer N
1 x 3-pole Phoenix contact socket external transformer L1
1 x 3-pole Phoenix contact socket external transformer L2
1 x 3-pole Phoenix contact socket external transformer L3
1 x 2-pole Phoenix contact socket Voltage measurement / internal transformer L1, max. 65 A
1 x 2-pole Phoenix contact socket Voltage measurement / internal transformer L2, max. 65 A
1 x 2-pole Phoenix contact socket Voltage measurement / internal transformer L3, max. 65 A
2 x 1-pole Phoenix contact socket N
1 x 1-pole Phoenix contact socket PE
Storage temperature -30 °C – +60 °C
Operating temperature -20 °C – +50 °C
Supply voltage 12 V or 24 V, automotive (12–13,5 V or 24–28 V)
Rated current consumption < 71 mA @ 12 V
< 36 mA @ 24 V
Housing ABS plastic
Protection class IP30
Overall dimensions 151 x 80 x 60 mm (L x B x H)
Weight 0,212 kg (circuit board, fitted)
FP part number 0023600 (Circuit board FP1405 V7)
Circuit board FP1405
