Panda fpControl
Page 18 - Chapter 2: Panda fpControl 27.5.20
Fig. 2.3.2-3: Overview Page 2 Symbols/EnglishOverview Page 3 (Generator):
09. Generator apparent power [kVA]
10. Power Factor
Note:In the case of 3-phase generators, the voltage, the
current and the electrical power are shown on separate
pages. Each page shows the value of one of the three
phases one below the other.
Fig. 2.3.2-4: Voltage display 3-P Symbols/English/Example of the voltage display of a 3-phase generator.
Fig. 2.3.2-5: Overview Page 3 Symbols/EnglishOverview Page 4:
09. Frequency of the generator [Hz]
10. Generator speed (r.p.m.)
11. Voltage of the starter battery [V]
To Next Page
