FläktGroup Multi-DENCO - Operating Limits Tables

Multi-DENCO Technical Description
FläktGroup DC-2013-0101-GB • Subject to modifications • R5-08/2020 23
3.2 Operating limits
Multi-DENCO
NOTE!
IMPORTANT: The following tables represent individual operating limits within the
devices. Not all combinations of limits will result in correct operation. For guidance
on suitable applications of your equipment, contact your local sales office.
Location Feature Property Unit A-Version F-Version P-Version
Min Max Min Max Min Max
Indoor Return Air Temperature °C 15 40
6
15 40 15 40
Indoor Return Air Absolute Humidity g/kg 2 18 2 18 2 18
Outdoor Return Air Temperature (Standard) °C -20 55 -20 55 -30
1
35
5
Outdoor Return Air
Temperature
(with Low Ambient Kit)
°C -40 55 N/A N/A N/A N/A
Misc Refrigerant
Condensing
Temperature
°C 35 64 35 64 35 64
Misc Refrigerant
Low Side - Operating
Pressure
MPa N/A 4.32 / 3.00
3
N/A 4.32 N/A 4.32
Misc Refrigerant
High Side - Operating
Pressure
MPa N/A 4.32 N/A 4.32 N/A 4.32
Indoor Inlet Water Temperature °C N/A N/A See note 2 See note 2 See note 2 See note 2
Indoor Water Delta Temperature °C N/A N/A See note 2 See note 2 See note 2 See note 2
Misc Water Glycol Concentration % N/A N/A 0 30 20 50
Misc Water Operating Pressure MPa N/A N/A N/A 0.6
4
N/A 0.6
4
Location Feature Property Unit C-Version W-Version X-Version
Min Max Min Max Min Max
Indoor Return Air Temperature °C 10 40 15 40
6
10 32
Indoor Return Air Absolute Humidity g/kg 2 18 2 18 2 18
Outdoor Return Air Temperature (Standard) °C N/A N/A N/A N/A -15 46
Outdoor Return Air
Temperature (with Low
Ambient Kit)
°C N/A N/A N/A N/A N/A N/A
Misc Refrigerant
Condensing Tempera-
ture
°C N/A N/A 35 64 35 64
Misc Refrigerant
Low Side - Operating
Pressure
MPa N/A N/A N/A 4.32 / 3.00
3
N/A 4.15
Misc Refrigerant
High Side - Operating
Pressure
MPa N/A N/A N/A 4.32 N/A 4.15
Indoor Inlet Water Temperature °C 3 35 25 45 N/A N/A
Indoor Water Delta Temperature °C 2 15 6 10 N/A N/A
Misc Water Glycol Concentration % 0 50 0 50 N/A N/A
Misc Water Operating Pressure MPa N/A 0.6
4
N/A 0.6
4
N/A N/A
1
Value is dependent on concentration of glycol. Value shown is based on minimum glycol concentration applied.
2
Water temperatures of FreeCool systems vary depending on ambient conditions, therefore no min / max can be specified.
3
4.32 MPa for unit sizes 010 → 065. 3.00 MPa for unit sizes 092 & 130.
4
Default tolerance for standard design. 1 MPa options available.
5
Limit is based on 100% cooling performance of unit's nominal. Higher ambient temperatures can be achieved with a lower cooling capacity.
6
30 °C Limit for sizes 092 & 130.
Tab. 3-1
