Overview of Units and Scope of Supply Multi-DENCO
8 FläktGroup DC-2013-0101-GB • Subject to modifications • R5-08/2020
1 Overview of Units and Scope of Supply
1.1 Introduction
We would like to thank you for purchasing our products.
Multi-DENCO units are intended and designed for indoor installation for cooling, heat-
ing, humidification, dehumidification and filtering of air at atmospheric pressure. The
units are designed as refrigeration systems and/or chilled water systems and it is pro-
hibited to use our units for any other purposes. The equipment has been designed and
manufactured within a 'Quality Assurance System' within a strict quality controlled envi-
ronment to ensure that it reaches you in perfect condition.
For help, assistance, spares or your local office, please visit the following website for
contact details in your region:
https://www.flaktgroup.com/en/contact-us/
1.2 Model number explained
Each product carries an 'Identification Plate' (sometimes referred to as 'serial plate')
inside the equipment for indoor units. For outdoor units, this is on the external casing.
This identification plate carries information that is important and unique to the unit.
Upon receipt of your equipment it is important to check the 'MODEL NUMBER' (a short-
ened version called 'Model Type Code' is shown on the serial plate) prior to positioning
and installation, to ensure it matches your requirements. Any discrepancies should be
reported immediately to your representative.
Refer to page 4 for the type code of a particular unit. Below shows an example serial
plate for a Multi-DENCO A-Version unit.
PRODUCT RANGE / PROJECT TYPE
Multi-DENCO® STANDARD
MODEL TYPE CODE / PED
DMA030DPSIN4PN1 CAT. 1
SERIAL NUMBER
CONTRACT NO. / DATE OF BUILD
110196 02 / 2017
OPERATION MAN. / WIRING DIAGRAM
PR-2013-0101 110196-101
VOLTAGE / PROTECTION RATING
400V-3PH-50HZ/60HZ+N
IP20
MAX. PRE-FUSE
32 TYPE D
FULL LOAD INPUT
11,4 kW
FULL LOAD CURRENT
29,9 A
COOLING MEDIUM
SOFTWARE VERSION
MWP HIGH PRESSURE SIDE
4,32 MPa
MWP LOW PRESSURE SIDE
4,32 MPa
CHILLED WATER
0,70 MPa
EMPTY WEIGHT
330,00 Kg
NOTE
6WC955
CV3.04.009B/DV4.06.009B
R410A (GWP 2088) & WATER
FIELD CHARGE (kg)
CO
2
e
1015
FläktGroup Czech Republic a.s.
Slovanská 781, 463 12 Liberec XXV - Vesec, Czech Republic
ANY MODIFICATION MAY NOT BE REFLECTED ABOVE
=
( Field Charge (R410A) / 1000 ) x 2088 = CO
2
e
CONTAINS
GREENHOUSE
FLUORINATED
GASES
