FLENDER ARPEX - Page 20

20
ARPEX 8706 en
Operating instructions 10/2017
MWF
14 2 3
44
*)
Fig. 11: Special type MWF
1"M" hub 2 "W" module (intermediate unit)
3"F" flange 4 Screw connection of flange
*
)
The plate packs must not be demounted or retightened!
MFB
14 2 43
*)
Fig. 12: Special type MFB
1"M" hub 2 "F" module (intermediate unit)
3"B" module 4 Screw connection of flange
*
)
The plate packs must not be demounted or retightened!
