6.11.3 Demounting the fitted coupling modules or components
Observe the safety instructions in section 6.1, "General information on fitting"!
Pull the "B", "X" modules and/or "M" hubs (see e.g. figs. 6 to 16), if possible with the aid of demounting
devices, off the shaft ends of the machines to be joined together.
WARNING
WARNING
Risk of serious injury through flying fragments
Risk of serious injury through falling coupling parts and/or flying fragments and/or risk of damage to the
coupling.
– The coupling module must be axially secured.
– Observe the permissible demounting pressure and temperature values specified on the
orderspecific drawing of the coupling.
WARNING
Danger of burns
Serious injury through burns on hot surfaces (> 55 °C) possible.
Wear suitable protective gloves and protective clothing.
In the case of "F" modules (see figs. 6 to 16) undo the screw connection to the customer’s flange or the
screw connection to the "F" flange, and demount the "F" module.
In the case of "F" flanges (see figs. 6 to 16) undo the screw connection to the customer’s flange and
demount the flange.
WARNING
Serious injury
Risk of serious injury through falling coupling parts and/or flying fragments and/or risk of damage to the
coupling.
Secure all coupling parts against falling before undoing the screw connection.
