19
ARPEX 8706 en
Operating instructions 10/2017
5.2.2 Special types
By exchanging individual coupling components and coupling modules, additional types can be generated
on the basis of the standard types (see item 5.2.1). As an example three special types, BVFF, MWF and
MFB, are shown in this section (see figs. 10 to 12).
Note
The exact arrangement of the coupling components, coupling modules, screw connections of the
flanges and further accessories such as shims can be found on the orderspecific drawing of the
coupling.
BVFF
12355
455
*)
Fig. 10: Special type BVFF
1"B" module 2 "V"-spacer (intermediate unit)
3"F" module 4 "F" flange
5 Screw connection of flange
*
)
The plate packs must not be demounted or retightened!
