6.8.3 Fitting the intermediate unit
Observe the safety instructions in section 6.1, "General information on fitting"!
Insert intermediate unit between the fitted coupling parts (see figs. 28 and 29).
2
11
Fig. 28: Fitting intermediate unit type BVB and XVX (basic drawing BVB, XVX identical)
1 Fitted coupling part
(e.g. "B" module)
2 intermediate unit (e.g. "V"-spacer)
1
1
2
Fig. 29: Fitting intermediate unit type MHM (basic drawing)
1 fitted coupling part (e.g. "M" module) 2 intermediate unit (e.g. "H" module)
