40
ARPEX 8706 en
Operating instructions 10/2017
S1
max
.
S1
min.
S1
min.
S1
max.
M
M
M
M
M
M
S1
max
.
S1
min.
S1
min.
S1
max.
M
M
M
M
M
M
BVB
MHM
Fig. 34: Flange distance "S1" and measuring points
M Measuring point
WARNING
Risk of serious injury through flying fragments
Risk of serious injury through flying fragments and/or risk of damage to the coupling.
The fitting misalignment must not exceed the values for S1
min.
and S1
max.
specified (figure 34). The
permissible values of "S1" are given in the table "Fitting data" on the orderspecific drawing of the
coupling.
