Remove the intermediate unit (see figs. 6 to 16).
WARNING
Serious injury
Risk of serious injury through falling coupling parts and/or flying fragments and/or risk of damage to the
coupling.
Secure all coupling parts against falling before undoing the screw connection.
After demounting the cheesehead bolts of the fastening (see figure 47) must imperatively be undone
again, so that the plate pack is detensioned and the cheesehead bolts remain only loosely screwed in.
Remove the cheesehead bolts (see figure 47) for transport purposes, so that the distance bushes
(see figure 47) can be inserted again. After this, insert the cheesehead bolts again and tighten them
handtight.
Fig. 47: Inserting the fastening
WARNING
Serious injury
Risk of serious injury through flying fragments and/or risk of damage to the coupling.
Fit the transport lock of the plate pack before transport.
