FLUXUS F70x 12 Data Logger and Transmission of Data
112 UMFLUXUS_F7V4-6-2EN, 2017-10-01
12 Data Logger and Transmission of Data
The transmitter has a data logger in which the measured values are stored during the measurement (see section 12.1).
In addition, the measurement data can be transmitted to a PC via the serial interface or stored on an SD card (see section
12.2). For the connection of the serial interface see section 7.6.
12.1 Data Logger
The following data will be stored:
•date
•time
• measuring point number
• pipe parameters
• medium parameters
• transducer data
• sound path (reflection or diagonal arrangement)
• transducer distance
• damping factor
• storage rate
• physical quantity
• unit of measurement
• measured values (physical quantity and input quantities)
• totalizer values (if the totalizers are activated)
• diagnostic values (if storing of diagnostic values is activated)
In order to store the measured data, the data logger has to be activated (see section 12.1.1).
The available data logger memory can be displayed (see section 12.1.6).
The storing of each measured value will be signaled acoustically. This signal can be deactivated (see section 12.1.3 in
Acoustic Signal).
12.1.1 Activation/Deactivation of the Data Logger
12.1.2 Setting the Storage Rate
The storage rate is the frequency at which the measured values are transmitted or stored. The storage rate is set sepa-
rately for each measuring channel.
If the storage rate is not set, the storage rate which was selected previously will be used.
The storage interval should be at least equal to the number of activated measuring channels, e.g., the storage interval of a
channel should be min. 2 s if 2 measuring channels are activated, min. 4 s are recommended.
Select in the program branch Output Options the channel for which the data logger is to
be activated. Press ENTER.
This display will not be indicated if the transmitter has only one measuring channel.
Press ENTER until the menu item Store Meas.Data is displayed.
Select yes to activate the data logger. Press ENTER.
Select a storage rate or EXTRA. Press ENTER.
This display will only be indicated if Store Meas.Data and/or Serial Output are acti-
vated.
If EXTRA has been selected, enter the storage rate. Press ENTER.
Output Options ↕
for Channel A:
Store Meas.Data
no >YES<
Storage Rate ↕
Once per 10 sec.
Storage Rate
1s
