FLUXUS F70x 13 Libraries
126 UMFLUXUS_F7V4-6-2EN, 2017-10-01
13.3.4 Input of Heat Flow Coefficients
Select Special Funct.\Install Medium. Press ENTER.
13.3.5 Input of the Steam Coefficients
Use the program FluxKoef (optional).
13.4 Deleting a User-Defined Material/Medium
To delete a user-defined material/medium, proceed as follows:
Select Special Funct.\Install Material or Install Medium. Press ENTER.
If the extended library is activated, press ENTER until the request for deleting is displayed.
Note! The heat flow coefficients can also be edited with the programs FluxData and FluxKoef.
Note! The entered coefficients will not be checked. Absurd values can result in wrong measured values or
in permanent system errors.
Select Heat-flow coeffs. Press ENTER.
This error message will be displayed if the coefficient memory does not contain an area for
the heat flow coefficients.
Partition the coefficient memory accordingly (see section 13.1).
Select the medium for which the heat flow coefficients have to be entered.
User-defined media will be displayed first, followed by the media of the internal database.
Select an index for storing the heat flow coefficients of the selected medium. Press EN-
TER.
If the coefficient memory is partitioned in such way that heat flow coefficients for two media
can be entered, indices 01 and 02 are available.
Enter the 10 heat flow coefficients: a0...a4, r0...r4. Press ENTER after each input.
Select yes to store the heat flow coefficients. Press ENTER.
Note! The entered coefficients will not be checked. Absurd values can result in wrong measured values or
in permanent system errors.
Select delete. Press ENTER.
Select the material/medium to be deleted. Press ENTER.
Select yes or no. Press ENTER.
Edit Medium ↕
Heat-flow coeffs
Heat-flow coeffs
NOT FORMATTED !
Select index ↕
02(--not used--)
Heat-flow coeffs
Save? no >YES<
Install Material
edit >DELETE<
USER Material
#01: Polystyrol
