FLUXUS F70x A Menu Structure
166 UMFLUXUS_F7V4-6-2EN, 2017-10-01
A Menu Structure
INIT-
resistant
Program Branch Parameter
main menu: selection of the program branch Parameter
selection of a measuring channel (A, B) or of a calculation channel (Y, Z)
This display will not be indicated if the transmitter has only one measuring chan-
nel.
When a Measuring Channel is Selected (A, B)
input of the outer pipe diameter
input of the pipe circumference
This display will only be indicated if Special Funct.\SYSTEM set-
tings\Dialogs/Menus\Pipe Circumfer. is activated and Outer Diam-
eter = 0 has been entered.
input of the pipe wall thickness
range: depends on the connected transducers
default: 3 mm
selection of the pipe material
input of the sound speed of the pipe material
range: 600...6553.5 m/s
This display will only be indicated if Other Material has been selected.
selection whether the pipe is lined
selection of the lining material
This display will only be indicated if Lining = yes has been selected.
input of the sound speed of the lining material
range: 600...6553.5 m/s
This display will only be indicated if Other Material has been selected.
input of the liner thickness
default: 3 mm
input of the roughness of the inner pipe wall
range: 0...5 mm
default: 0.1 mm (for steel as pipe material)
selection of the medium
input of the average sound speed of the medium
range: 500...3500 m/s
This display will only be indicated if Other Medium has been selected.
>PAR< mea opt sf
Parameter
Parameter ↕
for Channel A:
Pipe Material ↕
Carbon Steel
To Next Page
