Flexim FLUXUS F705**-NN Series User Manual

18 Outputs FLUXUS F70x
UMFLUXUS_F7V4-6-2EN, 2017-10-01 155
18.3.1 Measuring Range of the Analog Outputs
After an analog output has been activated in the program branch Output Options, the measuring range of the source
item has to be entered.
18.3.2 Function Test
The function of the installed output can now be tested. Connect a multimeter to the installed output.
18.4 Configuration of a Frequency Output as a Pulse Output
A frequency output sends a signal with a frequency that depends on the volume flow rate. The frequency output can be
configured in such way that the source item can be totalized by using each period of the output signal as the increment.
18.4.1 Installation of a Frequency Output (Optional)
Select sign if the sign of the measured values is to be considered for the output.
Select absolut if the sign is not to be considered.
Enter the lowest expected measured value. The unit of measurement of the source item
will be displayed.
Zero-Scale Val. is the measured value that corresponds to the lower limit of the output
range as defined in section 18.1.1.
Enter the highest expected measured value.
Full-Scale Val. is the measured value that corresponds to the upper limit of the output
range as defined in section 18.1.1.
Example: output: current output
output range: 4…20 mA
Zero-Scale Val.: 0 m³/h
Full-Scale Val.: 300 m³/h
volumetric flow rate = 0 m³/h, corresponds to 4 mA
volumetric flow rate = 300 m³/h, corresponds to 20 mA
Select yes to activate the output. Press ENTER.
Enter a test value for the selected physical quantity. If the multimeter displays the corre-
sponding current value, the output functions correctly. Press ENTER.
Select yes to repeat the test. Press ENTER.
Example: output: current output
output range: 4…20 mA
Zero-Scale Val.: 0 m³/h
Full-Scale Val.: 300 m³/h
Test value = 150 m³/h (center of the measuring range, corresponds to 12 mA)
If the multimeter displays 12 mA, the current output functions correctly.
Select Frequency F1 in Special Funct.\SYSTEM settings\Proc. outputs.
Press ENTER.
Select yes if the output has not been installed. Press ENTER.
or
Select no if the output has already been installed. Press ENTER.
Meas.Values
>ABSOLUT< sign
Zero-Scale Val.
0.00 m3/h
Full-Scale Val.
300.00 m3/h
I1: Test output ?
no >YES<
I1: Test value =
150.00 m3/h
I1: Test output ?
no >YES<
Install Output ↕
Frequency F1
F1 enable
no >YES<
F1 disable
>NO< yes
