Flexim FLUXUS F705**-NN Series - Transmitter FLUXUS F709

FLUXUS F70x 6 Installation
30 UMFLUXUS_F7V4-6-2EN, 2017-10-01
6.3 Transmitter FLUXUS F709
The transmitter is designed as a 19 " module (42 HP, 3 U).
Fig. 6.5: Installation of the transmitter
FLUXUS F704
Fig. 6.6: Installation of the transmitter FLUXUS F705, 706
(example with F705)
Fig. 6.7: Pipe installation using tension straps
Fig. 6.8: Front and back view
5
2
3
2
3
