14 Settings FLUXUS F70x
UMFLUXUS_F7V4-6-2EN, 2017-10-01 129
14 Settings
14.1 Time and Date
The transmitter has a battery-powered clock. Measured values are automatically stored with the date and time.
14.1.1 Time
14.1.2 Date
After the time has been set, DATE is displayed.
14.2 Dialogs and Menus
14.2.1 Pipe Circumference
Select
Special Funct.\SYSTEM settings
\
Set Clock. Press ENTER.
The current time is displayed. Select ok to confirm the time or new to set the time. Press
ENTER.
Press key and to select the digit to be edited.
Press key and to edit the selected digit. Press ENTER.
The new time is displayed. Select ok to confirm the time or new to set the time again. Press
ENTER.
Select ok to confirm the date or new to set the date. Press ENTER.
Press key and to select the digit to be edited.
Press key and to edit the selected digit. Press ENTER.
The new date is displayed. Select ok to confirm the date or new to set the date again.
Press ENTER.
Select Special Funct.\SYSTEM settings\Dialogs/Menus. Press ENTER.
Note! The settings of the menu item Dialogs/Menus will be stored at the end of the dialog. If the menu
item is quit before the end of the dialog, the settings will not be effective.
Select on if the pipe circumference is to be entered instead of the pipe diameter in the pro-
gram branch Parameter. Press ENTER.
If on has been selected for Pipe Circumfer., the outer pipe diameter will nevertheless
be requested in the program branch Parameter.
To select the menu item Pipe Circumfer., enter 0 (zero). Press ENTER.
The value displayed in Pipe Circumfer. is calculated on the basis of the last displayed
value of the outer pipe diameter.
example: 100 mm
.
= 314.2 mm
Enter the pipe circumference. The limits for the pipe circumference are calculated on the
basis of the limits for the outer pipe diameter.
SYSTEM settings↕
Set Clock
DATE 2011-01-25
Set Date !
SYSTEM settings↕
Dialogs/Menus
