9.4 Selection of the Channels
The channels on which a measurement is being made can be activated individually.
• Press key and to select a channel.
• Press key to activate or deactivate the selected channel. Press ENTER.
A deactivated channel will be ignored during the measurement. Its parameters will remain unchanged.
If the data logger or the serial interface is activated, the measuring point number has to be entered:
9.5 Defining the Number of Sound Paths
9.6 Transducer Distance
The transducer distance is the distance between the inner edges of the transducers (see section 3.3 and Fig. 6.9)
In case of a measurement in diagonal arrangement on very small pipes, a negative transducer distance is possible.
Select program branch Measuring. Press ENTER.
If this error message is displayed, the parameters are not complete. Enter the missing pa-
rameters in the program branch Parameter.
The channels for the measurement can be activated and deactivated.
: the channel is active
–: the channel is not active
•: the channel cannot be activated
This display will not be indicated if the transmitter has only one measuring channel.
Note! A channel cannot be activated if the parameters are not valid, e.g., if the parameters in the program
branch Parameter of the channel are not complete.
Enter the measuring point number. Press ENTER.
If arrows are displayed in the lower line on the right, ASCII text can be entered. If no arrows
are displayed, only digits, point and hyphen can be entered.
A number of sound paths is recommended according to the connected transducers and the
entered parameters. Change the value, if necessary.
Press ENTER.
For defining the number of sound paths, see section 3.3.
A value for the transducer distance is recommended. Fix the transducers (see section 6.4).
Adjust the transducer distance.
Press ENTER.
A - measuring channel
Reflec - reflection arrangement
Diagon - diagonal arrangement
Note! The accuracy of the recommended transducer distance depends on the accuracy of the entered pipe
and medium parameters.
par>MEA<opt sf
Measuring
par>MEA<opt sf
NO DATA!
CHANN:
MEASUR
<
>A< B Y Z
 - .
4
6
8
A:Meas.Point No.:
xxx (↑↓← →)
A:
2 NUM
A: Sound Path
2NUM
Transd. Distance
A:54 mm Reflec
