13 Libraries FLUXUS F70x
UMFLUXUS_F7V4-6-2EN, 2017-10-01 125
Material parameters
Enter the material's:
• transversal sound speed
• longitudinal sound speed
1...5 values depending on the selected function have to be entered. Press ENTER after each input.
If an already defined material is edited, for each parameter there will be a request whether it is to be edited. Select yes or
no. Press ENTER. Change the values, if necessary.
Medium parameters
Enter the medium's:
• longitudinal sound speed
• kinematic viscosity
• density
Depending on the selected function, 1...5 values have to be entered. Press ENTER after each input.
If an already defined medium is edited, for each parameter of some of the functions there will be a request whether it is to
be edited. Select yes or no. Press ENTER. Change the values, if necessary.
Select edit to edit the material/medium parameters or delete to delete the material/me-
dium and to return to the scroll list Edit Material or Edit Medium.
This display will only be indicated if an already existing material/medium has been select-
ed.
Enter the designation of the material/medium. Press ENTER.
The default name for a user-defined material/medium is USER MATERIAL N or USER ME-
DIUM N with N being an integer.
Select the type of sound wave to be used for the flow measurement. Press ENTER.
For most materials, a transversal sound wave has to be selected.
Enter the typical roughness of the material. Press ENTER.
Select yes to store the entered parameters or no to quit the menu item without storing.
Press ENTER.
Select yes to store the entered parameters, no to quit the menu item without storing. Press
ENTER.
USER MATERIAL 2
>EDIT< delete
#2: Input Name:
USER MATERIAL 2
Default soundsp.
long. >TRANS.<
