Flexim FLUXUS F705**-NN Series User Manual

18 Outputs FLUXUS F70x
UMFLUXUS_F7V4-6-2EN, 2017-10-01 151
Tab. 18.1: Configuration of the outputs
source item list item output
Measuring value actual measure physical quantity selected in the program branch Output Options
Flow flow, independently of the physical quantity selected in the program
branch Output Options
Heatflow heat flow, independently of the physical quantity selected in the program
branch Output Options
Quantity Q+ totalizer for the positive flow direction
* actual measure totalizer for the physical quantity selected in the program branch Out-
put Options
* Flow flow totalizer
* Heatflow totalizer for the heat flow
Q- totalizer for the negative flow direction
* actual measure totalizer for the physical quantity selected in the program branch Out-
put Options
* Flow flow totalizer
* Heatflow totalizer for the heat flow
Q sum of the totalizers (positive and negative flow direction)
* actual measure totalizer for the physical quantity selected in the program branch Out-
put Options
* Flow flow totalizer
* Heatflow totalizer for the heat flow
Limit R1 limit message (alarm output R1)
R2 limit message (alarm output R2)
R3 limit message (alarm output R3)
Temperature Is only available if a temperature input has been assigned to the channel.
Tfluid ← (Ti) medium temperature of the temperature probe at the point where the
flow is measured
Taux S/R ← (Ti) medium temperature of the other temperature probe
Tsupply ← (Ti) supply temperature
Treturn ← (Ti) return temperature
Ts-Tr (Ti-Tj) difference supply temperature-return temperature
Tr-Ts (Ti-Tj) difference return temperature-supply temperature
T(3) ← (Ti) third temperature input of the measuring channel
T(4) ← (Ti) fourth temperature input of the measuring channel
* i, j: number of the assigned temperature input
Impuls from abs(x) pulse without sign consideration
from x > 0 pulse for positive measured values
from x < 0
pulse for negative measured values
Miscellaneous c-Medium sound speed of the medium
Signal signal amplitude of a measuring channel
SCNR ratio useful signal to correlated disturbance signal
VariAmp standard deviation of the signal amplitude
Density density of the medium
