Technical data22
Laser pointer
Laser Activated by dedicated button
Laser classification Class 2
Laser type Semiconductor AlGaInP diode laser, 1 mW, 635
nm (red)
USB
USB
• USB-A: Connect external USB device
• USB Mini-B: Data transfer to and from PC
USB, standard USB Mini-B: 2.0 high speed
Composite video
Video out Digital video output (image)
Power system
Battery type Rechargeable Li ion battery
Battery voltage 7.2 V
Battery capacity 4.4 Ah
Battery operating time > 3 hours at 25°C (+77°F) and typical use
Charging system In camera (AC adapter or 12 V from a vehicle) or 2-
bay charger
Charging time 2.5 h to 95% capacity, charging status indicated by
LED's
External power operation AC adapter 90–260 VAC, 50/60 Hz or 12 V from a
vehicle (cable with standard plug, optional)
DC operation 10.8 to 16 V DC, polarity protected (proprietary
protected)
Power 8.5 W typically
Start-up time Typically 7 min. @ 25°C (+77°F)
Environmental data
Operating temperature range –20°C to +50°C (–4°F to +122°F)
Storage temperature range –30°C to +60°C (–22°F to +140°F)
Humidity (operating and storage) IEC 68-2-30/24 h 95% relative humidity +25°C to
+40°C (+77°F to +104°F) (2 cycles)
Directives
• 73/23EEC
• 2004/108/EC
• 2002/95/EC
• 2002/96/EC
EMC
• EN61000-6-4 (Emission)
• EN61000-6-2 (Immunity)
• FCC 47 CFR Part 15 class A (Emission)
• EN 61 000-4-8, L5
Encapsulation IP 54 (IEC 60529)
Shock 25 g (IEC 60068-2-27)
Vibration
2 g (IEC 60068-2-6)
Safety Power supply: EN/UL/IEC 60950-1
#T559157; r. AH/45951/45951; en-US
172
