Working with measurement tools
18
18.1 Laying out a measurement tool
18.1.1 General
To measure a temperature, you use one or several measurement tools, such as a spot-
meter, a box, etc.
18.1.2 Procedure
Follow this procedure to lay out measurement tool:
1. Turn the mode wheel to
or .
2. Push the
button to display a menu.
3. Move the joystick left/right to go to the Edit tab.
4. Move the joystick up/down to select the measurement tool you want to lay out.
5. Push the joystick. The measurement tool has now been created on the screen.
18.2 Moving or resizing a measurement tool
18.2.1 General
You can move and resize a measurement tool.
18.2.2 Procedure
Note This procedure assumes that you have previously laid out a measurement tool on
the screen.
Follow this procedure to move or resize a measurement tool:
1. Turn the mode wheel to
or .
2. Push the
button to display a menu.
3. Move the joystick left/right to go to the Edit tab.
4. Move the joystick up/down to select the measurement tool that you want to move or
resize.
5. Push the joystick to display a menu.
6. Move the joystick up/down to select Move or Resize.
7. Move the joystick up/down and left/right to move or resize the measurement tool.
8. Push the joystick to confirm.
9. Push the
button to leave the setup mode.
18.3 Creating & setting up a difference
calculation
18.3.1 General
A difference calculation returns the difference between the values of two known measure-
ment results, or between the value of a measurement result and the reference
temperature.
#T559157; r. AH/45951/45951; en-US
64
