M3100 Series Hard Drive Installation
21
4. Disconnect the SATA power and data cable from the hard drive.
5. Carefully turn the system over. Slide the hard drive and then lift it out of the system.
6. Replace the cover and cover screws (6x).
Note
After installation, you must format the hard drive in order to use it with the system. See 21.3 Format-
ting Hard Drives, page 158.
21.3 Formatting Hard Drives
You must format hard drives before you may use them with the system.
CAUTION
Formatting the HDD erases all data on the hard disk. This step cannot be undone. System settings will
not be erased.
To format the hard drive:
1. From the Main Menu, click
and then click Storage>HDD Manager.
#LX400028; r. 1.0/16141/16141; en-US
158
