FLIR M3100 SERIES User Manual

Using the Main Menu15
3. Configure the following settings for snapshots saved automatically from motion detec-
tion or the snapshot schedule:
• Channel: Select the channel you would like to configure.
• Mode: Select Timing for the system to take snapshots according to the snapshot
schedule (see 15.3.14 Configuring the Snapshot Schedule, page 58) Select Trig-
ger for the system to take snapshots only when triggered by motion detection
(snapshot must be enabled in the Motion Detect menu (see 15.3.7 Configuring Mo-
tion Detection, page 52).
• Image Size: Select the resolution for snapshots.
• Image Quality: Select the snapshot image quality between 1 (lowest) and 6
(highest)
• Snapshot Frequency: Select the number of snapshots (up to 6) the system will
take each time.
4. Click OK to save changes.
15.1.5 Creating Custom Channel Names
You can assign custom names to your cameras. For example, you can name your cameras
based on their location (e.g. hallway or front door).
To create custom channel names:
1. From the Main Menu, click
and select Channel Name.
2. Enter a custom name for each channel.
3. Click OK to save changes.
#LX400028; r. 1.0/16141/16141; en-US
43

FLIR M3100 SERIES Specifications

General

Brand	FLIR
Model	M3100 SERIES
Category	DVR
Language	English
