Using the Main Menu15
The Record Info menu shows the start and end times of recordings saved on the hard
drive.
To access the Record Info menu:
• From the Main Menu, click
and then select Info>Record Info.
15.2.3 Version
The Version sub-menu allows you to view information about the current firmware installed
on the system.
To access the Version menu:
• From the Main Menu, click
and then click Info>Version.
15.2.4 Alarm Status
The Alarm Status menu shows you a display of system alarms. Activated alarms are high-
lighted in white. Additional info such as channels that are currently detecting motion is
shown.
The following alarms are shown in the Alarm Status menu:
• No HDD: No hard drive is detected.
• Disk Error: Hard drive error detected.
• Disk Full: Hard drive is full.
• Net Disconnection: System is not connected to the network.
• IP Conflict: More than one device on the network is using the same IP address.
• MAC Conflict: More than one device on the network is using the same MAC address.
• Local Alarm: Not supported.
• Net Alarm: Not supported.
#LX400028; r. 1.0/16141/16141; en-US
45
