Using the Main Menu15
To configure Motion Detection events:
1. From the Main Menu, click
and then click Event>Motion>Motion Detect.
2. Under Channel, select the channel you would like to configure.
3. Check Enable to enable motion detection on the selected channel.
4. Click Setup next to Region to configure which areas of the image will be enabled for
motion detection. A grid will appear on the monitor.
Motion Grid
• Areas enabled for motion detection are shown in color and areas that are disabled are transparent.
• You can set up to 4 motion detection areas and customize the sensitivity and threshold for motion de-
tection separately for each one. Hover the mouse at the top of the screen to select which motion
area you would like to configure.
• Right-click when finished.
5. Under Anti-dither, enter the anti-dither time. After a motion event occurs and motion
stops, if motion is detected within the anti-dither time, the system continues the motion
event and includes the new motion within the first event, rather than creating a new
motion event.
6. Under Post_REC, enter the time the system will record after a motion event occurs.
#LX400028; r. 1.0/16141/16141; en-US
53
