Figure 14.10 Horizontal, vertical and instantaneous fields of view for certain distances to targets. 14.7 mm
lens / camera type 301.
Figure 14.11 F-number and close focus limits for various lenses
14.7 mm27.4 mm46.2 mmIR lens →
0.200.300.50Close focus limit (m)
0.660.981.64Close focus limit (ft.)
1.51.51.5f-number
14
98 Publ. No. 1558407 Rev. a155 – ENGLISH (EN) – February 6, 2006
14 – Technical specifications & dimensional drawings
