ExplanationValueLabel
■
Select Off to disable the alarm
■
Select Above to assign an alarm color to all
pixels above the alarm temperature
■
Select Below to assign an alarm color to all
pixels below the alarm temperature
■
Off
■
Above
■
Below
Alarm
■
Select Color only to assign only a color to the
pixels when an alarm is triggered.
■
Select Silent to additionally make the font of
the temperature result increase in size and be
displayed against a red background (i.e. a visu-
al alarm)
■
Select Beep to additionally make the camera
trigger a beep when an alarm is triggered.
■
Color only
■
Silent
■
Beep
Alarm output
Enter an delta alarm value by pressing the naviga-
tion pad left/right.
➲ This label is only available if Update ref temp
has been previously selected in the Settings dialog
box.
N/ADelta alarm
For information purposes only.
The reference temperature is calculated and updat-
ed ’on the fly’.
➲ This label is only available if Update ref temp
has been previously selected in the Settings dialog
box.
User-definedRef temp
Enter a temperature value by pressing the naviga-
tion pad left/right.
User-definedAlarm temp
10.4.3 Manual adjust/Automatic adjust
Point to Manual adjust and press MENU/YES to manually select level and span set-
tings. The level command can be regarded as the brightness, while the span command
can be regarded as the contrast.
■ Press the navigation pad up/down to change the level (indicated by an arrow
pointing upwards or downwards in the temperature scale)
■ Press the navigation pad left/right to change the span (indicated by two arrows
pointing away from each other or towards each other)
10
70 Publ. No. 1558407 Rev. a155 – ENGLISH (EN) – February 6, 2006
10 – Camera program
