FLIR ThermaCAM E320 - Changing Level & Span; Changing Level; Changing Span

8.6 Changing level & span
8.6.1 Changing level
ActionStep
Press MENU/YES to display the vertical menu bar.1
Point to Manual adjust on the vertical menu bar and press MENU/YES.2
Press the navigation pad up/down to change the level. An arrow pointing upwards
or downwards will be displayed.
3
For more information about level, see section 10.4.3 – Manual adjust/Automatic adjust
on page 70.
8.6.2 Changing span
ActionStep
Press MENU/YES to display the vertical menu bar.1
Point to Manual adjust on the vertical menu bar and press MENU/YES.2
Press the navigation pad left/right to change the span. Two arrows pointing away
from each other or towards each other will be displayed.
3
For more information about span, see section 10.4.3 – Manual adjust/Automatic adjust
on page 70.
8
Publ. No. 1558407 Rev. a155 – ENGLISH (EN) – February 6, 2006 49
8 – Tutorials
