8.4.3 Setting up a silent alarm (i.e. a visual alarm)
ActionStep
Press MENU/YES to display the vertical menu bar.1
Point to Meas. mode and press YES to display the Meas. mode dialog box.2
Select Meas. mode by pressing the navigation pad left/right. The alarm function
is typically used together with Area max.
3
For Alarm, select one of the following by pressing the navigation pad left/right:
■
Above
■
Below
4
For Alarm output, select Silent by pressing the navigation pad left/right.5
Specify the Alarm temp by pressing the navigation pad left/right.
➲ Alarm temp will only be available if Update ref temp has been previously selected
in the Settings dialog box.
6
Specify Delta alarm by pressing the navigation pad left/right.
➲ Delta alarm will only be available if Update ref temp has been previously selected
in the Settings dialog box.
7
8.4.4 Setting up an audible alarm
ActionStep
Press MENU/YES to display the vertical menu bar.1
Point to Meas. mode and press YES to display the Meas. mode dialog box.2
Select Meas. mode by pressing the navigation pad left/right. The alarm function
is typically used together with Area max.
3
For Alarm, select one of the following by pressing the navigation pad left/right:
■
Above
■
Below
4
For Alarm output, select Beep by pressing the navigation pad left/right.5
Specify the Alarm temp by pressing the navigation pad left/right.
➲ Alarm temp will only be be available if Update ref temp has been previously
selected in the Settings dialog box.
6
Specify Delta alarm by pressing the navigation pad left/right.
➲ Delta alarm will only be available if Update ref temp has been previously selected
in the Settings dialog box.
7
8
Publ. No. 1558407 Rev. a155 – ENGLISH (EN) – February 6, 2006 47
8 – Tutorials
