FLIR ThermaCAM E320 User Manual

ExplanationValueLabel
■
Select On to display the information field at the
bottom of the screen
■
Select Off to hide the information field
■
Select On + TRefl to display the information
field and the reflected ambient temperature
■
On
■
Off
■
On + TRefl
Info field
■
Select Laser to activate the laser when pulling
the trigger
■
Select Save to save the current image when
pulling the trigger
■
Select Disabled to disable the trigger
■
Select One-shot autoadjust to autoadjust the
camera when pulling the trigger
■
Select Update ref. temp to update the reference
temperature when pulling the trigger
If Update ref. temp. is selected:
By pulling the trigger for more than 1 second, a
dialog displaying the message Restart ref temp
at nn.n °C? will appear.
Do one of the following:
■
Select OK to purge the internal camera buffer
and begin a new sampling sequence
■
Select Cancel to leave the dialog box
■
Laser
■
Save
■
Disabled
■
One-shot autoadjust
■
Update ref. temp.
Trigger
■
Select Low to set the LCD intensity to the lowest
level
■
Select Medium to set the LCD intensity to
medium level
■
Select High to set the LCD intensity to the
highest level
■
Low intensity of the
LCD
■
Medium
■
High
LCD intensity
If the camera is switched on but currently not used,
it will automatically be switched off after a specified
time.
Set the time by pressing the navigation pad
left/right.
■
None
■
2 min
■
5 min
■
10 min
Auto power off
If the camera is switched on but currently not used,
the display will automatically be switched off after
a specified time.
Set the time by pressing the navigation pad
left/right.
■
None
■
30 sec.
■
60 sec.
■
2 min.
Display power off
If you want to be prompted for adding an image
description when saving an infrared image, select
On.
■
On
■
Off
Prompt img. desc.
10
Publ. No. 1558407 Rev. a155 – ENGLISH (EN) – February 6, 2006 75
10 – Camera program
