732B/734A
Instruction Manual
3-8
732B-7001 EXTERNAL BATTERY/CHARGER
AC PWR CHARGE LOW BAT
2 31
4
SERIAL NUMBER
k7f.eps
Figure 3-3. 732B-7001 External Battery/Charger Front Panel Features
Table 3-3. 732B-7001 External Battery/Charger Front Panel Features
Item Feature Description
1 AC PWR Indicator Lights whenever the battery unit is connected to ac line power.
2 CHARGE Indicator Lights when the battery unit is in the constant-current charging
mode. When the battery is near full charge, the CHARGE
indicator goes off, and the charging circuit goes into float-
charging mode to complete and maintain full charge.
3 LOW BAT Indicator Blinks when approximately 5 hours of battery operation time
remain. When LOW BAT blinks, plug the battery unit into ac
line power as soon as possible to avoid loss of power to an
attached 732B DC Standard.
4 Serial Number Use this identifier in your correspondence with Fluke.
